Model:
GUSU chocolate belt coating machine is advanced equipment for chocolate coating, especially for chocolate bean, nuts, dry fruit and so on. chocolate belt coating machine has bigger production capacity than coating pans. chocolate belt coating machine is automatically controlled by the PLC program, installed with a system of recipe save and automatic weighing. The flow of chocolate mass, the capacity of cold wind, the speed of mesh belt moving are adjustable. By automatic molding procedures and automated control program, the machine can automatically make chocolate beans.
Description
Dimensions
Features：
1.Stainless steel structure for wash easily.
2.Full automatic and exact chocolate coating metering valve.
3.Convenient and detachable system for recovery of scrap material.
4.There are four legs with the automatic weighing system(loadcell).
5.There is a chocolate mass adjustment valve to control the flow rate of chocolate mass.
6.Full automatic program control, Adopts PLC control, According to different product's features, can be set spray capacity and spray time by program.
7.Edible grade PU belt.Paste will rotary in high speed with function of belt.
8.Automatic feeding system main consist of chocolate storage tank, chocolate slurry pump, stainless steel interlayer insulating pipe.
Main consist of 3 machines as following :
(1).chocolate coating machine
(2).chocolate material feeding system
(3).industrial refrigeration units(water cooling and forced air cooling)
|
Power |
4kW |
|
L*W*H |
|
|
Capacity |
60-120kg/batch |
|
Batch Time |
40-60min |
|
Weight |
1500kg |
|
Cold Air Capacity |
2800 cubic meters/hour |
|
Wind Pressure |
250pa |
Founded in
Factory Area
Skillful Employees
Gusu Food Processing Machinery Suzhou Co.,Ltd. is a high-tech enterprise integrating R&D, manufacturing, production, sales and after-sales. Since 1969, focusing on the development and production of chocolate complete equipment and automatic energy bar production line, is China's first manufacturing chocolate complete equipment enterprises, according to customer needs, to provide a complete set of chocolate equipment solutions. Known as the "mother of China chocolate" in the industry, LBYJ1500 Chocolate Belt Coating Machine Manufacturers.
Main products include: melting pot, powdered sugar machine, chocolate grinding equipment, chocolate tempering machine, chocolate molding line, cookie pouring machine, energy bar cereal bar production line and so on. Complete product specifications, support customization. LBYJ1500 Chocolate Belt Coating Machine Customized
. The company is located in China's economic development, the beautiful scenery of Suzhou, with more than 50 years of chocolate equipment industry experience, perfect service system, professional and technical personnel of nearly 100 people, the factory covers an area of 35,000 square meters. LBYJ1500 Chocolate Belt Coating Machine Suppliers, products exported to 130 countries, With Mars, Barry Callebaut, Nestle, Cadbury, Heluxue, Glico, Good good, Meiji and many other well-known enterprises to establish long-term cooperative relations. After years of development, won a number of national patents, products through ISO9001:2008 certification and CE certification. We adhere to customer demand as the center, continuous innovation, accumulation, to promote the progress of chocolate equipment market.
