Model:
Chocolate Bar Line Snickers production line enables precise control of product size and weight, easy disassembly, and easy replacement and cleaning of all components. The Chocolate Bar Line Snickers production line uses a compound group roller, which can produce not only oatmeal bars but also Snickers bars, chocolate bars, and other multi-layer bar products. The roller is equipped with antifreeze oil (brine tank preparation) so that the bar product cooling molding is easier. All parts in contact with the product are made of SUS304 material. The conveyor belt control and temperature control are accurate, and the whole line integrates a series of production actions such as stirring, lifting, feeding, pressing, cooling, and cutting. Chocolate Bar Line The Snickers production line is the choice for food manufacturers to produce nutritional cereal bars, protein chocolate bars, nubuck, and Snickers bars.
Description
Dimensions
Versatility
Automatic Compound Candy Bar Line is designed to meet the fast-growing market for bar products like Snicker, Nougat, Cereal Bar, Grains Bar, Energy Bar, Fruit Bar, etc.
High Automatic
All functions of the bar forming line are regulated by means of one or two PLC control cabinets. Full PLC control and touch-sensitive Siemens provide full process visualization and recipe management.
Hygiene and Ease of Maintenance
Easy removal of all components for product changeover and clean down. Clear access into the cooling tunnel for cleaning and maintenance
Productivity
Regimented discharge options for enrobing application. Continue the process for minimal product wastage. Accurate control of product dimensions and weight.
Model | TPX200 | TPX300 | TPX400 | TPX600 | TPX800 |
Single Group Roller Width (mm) | 150-200 | 280-330 | 380-430 | 580-630 | 780-830 |
Compound Group Roller Width (mm) | 150-200 | 280-330 | 380-430 | 580-630 | 780-830 |
Flatten Roller Width (mm) | 150-200 | 280-330 | 380-430 | 580-630 | 780-830 |
Roller Temperature(℃) | —20~—70 | ||||
Longitudinal Cutter | 2 Units | 2 Units | 2 Units | 2 Units | 2 Units |
Temperature Control | Omron | ||||
Electronics Components | Schneider | ||||
Linear Speed (m/min) | 0-2.5 |
