Model:
Full Automatic Protein Bar Line The Protein Bar Production Line is mainly used in large and medium food industry production, suitable for a variety of bar products, such as energy bars, granola bars, cereal bars, protein bars, fruit bars, nougat, and so on. Its width includes 200,300,400,600 and 800mm, the forming line function can be adjusted by PLC control, product length, and width can be adjusted according to requirements, and the production of different sizes of rod products, Full Automatic Protein Bar Line Protein Bar Production Line is an ideal equipment for the modern food industry.
Description
Dimensions
Features:
1. PLC touch screen, friendly interface, simple operation
2. Protein bar production line is safe and reliable with high automation
3. The Full Automatic Protein Bar Line Protein Bar Production Line has large output and high efficiency. The production line has multiple rollers, does not waste materials, and makes the surface of the protein bar smooth and uniform thickness
4. Can process various sizes of grain bar production line, the size of the cutter is adjustable
| Model | TPX200 | TPX300 | TPX400 | TPX600 | TPX800 |
| Single Group Roller Width (mm) | 150-200 | 280-330 | 380-430 | 580-630 | 780-830 |
| Compound Group Roller Width (mm) | 150-200 | 280-330 | 380-430 | 580-630 | 780-830 |
| Flatten Roller Width (mm) | 150-200 | 280-330 | 380-430 | 580-630 | 780-830 |
| Roller Temperature(℃) | —20～—70 | ||||
| Longitudinal Cutter | 2 Units | 2 Units | 2 Units | 2 Units | 2 Units |
| Temperature Control | Omron | ||||
| Electronics Components | Schneider | ||||
| Linear Speed (m/min) | 0-2.5 | ||||
