Model: GQDJ400,600,800,1200
GQDJ Series Chocolate chips making machine chocolate chips rotary depositor is mainly used to produce chocolate granules. It can produce chocolate chips with tails at the top (like a water drop) or without tails at the top (like a button). Chocolate chip rotary depositors can produce pure chocolate or compound chocolate particles of various shapes and weights. The weight and size of the chocolate particles can be adjusted in the machine according to your requirements to meet different production needs, with a of 0.03 grams. These chocolate particles are very suitable for baking raw materials, or decorative products for the baking industry. Especially cookies and ice cream.
The chocolate chip rotary depositor is composed of a depositors and cooling tunnel, controlled by a PLC system, and the parameters can be adjusted on the touch screen. 400,600,800,900,1000,1200mm width optional, full automation, which can realize continuous production, large quantity, is the ideal equipment for small particles of chocolate products.
Gusu Machinery GQDJ series chocolate rotary depositor is a special equipment for the production of small particles of chips-shaped and button-shaped chocolate products. It is rolled on the food-grade PU conveyor belt with high precision through the chocolate supply system and pressure controller and automatically discharges after cooling in the cooling tunnel.
To achieve continuous production, large output, and easy operation, it only takes one person two minutes to flexibly change the outer roller to change different chocolate varieties and sizes.
Description
Dimensions
5, GQDJ600 drum drip machine (cold channel length according to actual requirements)
1 Total power 9.75w, motor power 2.25kw, heating power 3kw
2 Output 150-400kg/h, the specific output is related to the product
3 The drum drip pouring head needs to be equipped with a slurry supply system and pipelines
4 Frame made of ordinary stainless steel, material contact part made of 304 stainless steel. The equipment includes transmission components, a cooling tunnel, drip pouring, top die. The unit comes with a hot water tank and Grundfos pump to provide jacketed warm water for the hopper.
5 Belt width 600mm, belt speed 4-8 m/min (continuous movement)
6 with control box, and button control; Component brand: Chint; Thermostat brand: Yudian
7 Dimensions: 17500x950x1600mm
6, GQDJ800 drum drip machine (cold channel length according to actual requirements)
1 Total power 15.75w, motor power 2.25kw, heating power 3kw
2 Output 200-550kg/h, the specific output is related to the product
3 The drum drip pouring head needs to be equipped with a slurry supply system and pipelines
4 Frame made of ordinary stainless steel, material contact part made of 304 stainless steel. The equipment includes transmission components, a cooling tunnel, drip pouring, top die. The unit comes with a hot water tank and Grundfos pump to provide jacketed warm water for the hopper.
5 Belt width 800mm, belt speed 4-8 m/min (continuous movement)
6 with control box, and button control; Component brand: Chint; Thermostat brand: Yudian
7 Dimensions: 19500x1150x1600mm
7, GQDJ1000 drum drip machine (cold channel length according to actual requirements)
1 Total power 19.75w, motor power 3.3kw, heating power 3kw
2 Output 250-700kg/h, the specific output is related to the product
3 The drum drip pouring head needs to be equipped with a slurry supply system and pipelines
4 Frame made of ordinary stainless steel, material contact part made of 304 stainless steel. The equipment includes transmission components, a cooling tunnel, drip pouring, top die. The unit comes with a hot water tank and Grundfos pump to provide jacketed warm water for the hopper.
5 Belt width 1000mm, belt speed 4-8 m/min (continuous movement)
6 with control box, and button control; Component brand: Chint; Thermostat brand: Yudian
7 Dimensions: 19500x1350x1600mm
Model | Conveyor Belt Width(mm) | Tunnel Work Temp | Total Power(kW) | Outer Dimension(mm) |
GQDJ400 | 400 | 0-10° | 8 | 16500x1560x1300 |
GQDJ600 | 600 | 0-10° | 9.55 | 16500x1760x1300 |
GQDJ800 | 800 | 0-10° | 10.45 | 16500x1960x1300 |
GQDJ1200 | 1200 | 0-10° | 17.6 | 20500x1560x1303 |
Founded in
Factory Area
Skillful Employees
Gusu Food Processing Machinery Suzhou Co.,Ltd. is a high-tech enterprise integrating R&D, manufacturing, production, sales and after-sales. Since 1969, focusing on the development and production of chocolate complete equipment and automatic energy bar production line, is China's first manufacturing chocolate complete equipment enterprises, according to customer needs, to provide a complete set of chocolate equipment solutions. Known as the "mother of China chocolate" in the industry, GQDJ400,600,800,1200 Chocolate Chips Making Machine Chocolate Chips Rotary Depositor Manufacturers.
Main products include: melting pot, powdered sugar machine, chocolate grinding equipment, chocolate tempering machine, chocolate molding line, cookie pouring machine, energy bar cereal bar production line and so on. Complete product specifications, support customization. GQDJ400,600,800,1200 Chocolate Chips Making Machine Chocolate Chips Rotary Depositor Customized
. The company is located in China's economic development, the beautiful scenery of Suzhou, with more than 50 years of chocolate equipment industry experience, perfect service system, professional and technical personnel of nearly 100 people, the factory covers an area of 35,000 square meters. GQDJ400,600,800,1200 Chocolate Chips Making Machine Chocolate Chips Rotary Depositor Suppliers, products exported to 130 countries, With Mars, Barry Callebaut, Nestle, Cadbury, Heluxue, Glico, Good good, Meiji and many other well-known enterprises to establish long-term cooperative relations. After years of development, won a number of national patents, products through ISO9001:2008 certification and CE certification. We adhere to customer demand as the center, continuous innovation, accumulation, to promote the progress of chocolate equipment market.
News center
Gusu Food Processing Machinery Suzhou Co., Ltd.'s Chocolate Chips Rotary Depositor is a perfect solution for accurate feeding and stable production.
Gusu Food Processing Machinery Suzhou Co., Ltd., established in 1969, is a pioneering high-tech enterprise that integrates research and development, manufacturing, production, sales, and after-sales service in the chocolate equipment industry. Known as the "mother of China’s chocolate," Gusu has become a household name in the chocolate equipment market, offering a comprehensive range of products, including chocolate complete equipment and automatic energy bar production lines. Over the years, Gusu has earned a reputation for its unwavering commitment to quality and innovation, making it one of China’s leading chocolate equipment manufacturers.
As part of its extensive product lineup, Gusu offers the Chocolate Chips Rotary Depositor, a high-performance machine designed to meet the growing demands of the chocolate manufacturing industry for accurate feeding and stable production. This equipment is tailored for producing uniform and consistent chocolate chips, ideal for various chocolate products, including cookies, snack bars, and other confectioneries.
In the fast-paced and highly competitive chocolate manufacturing industry, maintaining consistency in the production process is essential. Chocolate chips, often used as an ingredient or decoration in various products, require precision in their size, shape, and weight. Even the smallest deviations can lead to inconsistencies in product quality, affecting consumer satisfaction and brand reputation.
Accurate feeding and stable production are critical to achieving the desired chocolate chip characteristics, and the Chocolate Chips Rotary Depositor from Gusu provides an ideal solution to these challenges. The machine offers precise control over the amount and distribution of chocolate, ensuring that each batch of chips is uniform in size and quality.
The Gusu Chocolate Chips Making Machine is designed to ensure accurate feeding of the chocolate. By utilizing a rotary mechanism, the depositor deposits chocolate chips with great precision. This guarantees that every chip is of the right size, weight, and shape, contributing to the overall consistency of the finished product.
The depositor is engineered for high-speed, continuous production. This means that manufacturers can maintain a steady output without the need for frequent adjustments, resulting in improved efficiency and reduced downtime. Whether for small-scale artisanal production or large-scale industrial manufacturing, this equipment ensures stable performance and reliability throughout the production cycle.
One of the key advantages of the Chocolate Chips Rotary Depositor is its versatility. It is suitable for producing a wide range of chocolate chips, from small, finely shaped chips to larger, more irregular ones. The machine can be easily adjusted to meet different production needs, offering flexibility to manufacturers looking to create different types of chocolate chips for various applications.
Gusu understands the importance of ease of operation in a fast-paced production environment. The Chocolate Chips Rotary Depositor comes with a user-friendly control system that allows operators to quickly set parameters and monitor the production process. This reduces the risk of human error and ensures that the equipment operates efficiently and effectively.
Maintaining hygiene in chocolate production is crucial, as it directly impacts product quality and safety. The Chocolate Chips Rotary Depositor is designed with easy-to-clean surfaces and components, ensuring compliance with hygiene standards. This is especially important in industries like confectionery, where product contamination can lead to recalls and reputational damage.
Built with high-quality materials and engineered for longevity, the Chocolate Chips Rotary Depositor is designed to withstand the demands of continuous operation. Gusu’s equipment is known for its durability and reliability, providing manufacturers with a long-lasting solution that minimizes maintenance and repair costs.
The Chocolate Chips Rotary Depositor is a versatile tool that can be used across a variety of chocolate production lines. Some of the most common applications include:
Chocolate chips are an essential ingredient in cookies and biscuits, and the Rotary Depositor ensures they are consistently distributed with uniform size and shape. This results in cookies with perfectly sized chocolate chips, creating an ideal texture and taste.
Energy bars, cereal bars, and granola bars often contain chocolate chips as a key ingredient. The depositor ensures these bars are filled with evenly distributed chocolate chips, improving both their appearance and taste.
The depositor can also be used for producing other chocolate confections such as chocolate-covered snacks or chocolate drizzled onto different products, ensuring a uniform application.
For manufacturers looking to create bespoke chocolate products, the depositor’s flexibility allows for customization of the size and shape of the chocolate chips to suit specific recipes and customer preferences.
Gusu Food Processing Machinery Suzhou Co., Ltd. has spent more than five decades leading the development of chocolate processing technologies. The company has established long-term relationships with global chocolate giants such as Mars, Nestlé, Cadbury, and Barry Callebaut, underscoring its reputation for excellence and reliability in the industry.
In addition to its cutting-edge equipment, Gusu offers a complete set of chocolate production solutions, customized to meet the unique needs of each customer. The company’s commitment to research and development, as well as continuous innovation, has led to the creation of several patented technologies that drive the progress of the chocolate equipment market.
All Gusu products are ISO 9001:2008 and CE certified, ensuring that they meet international quality and safety standards. The company’s state-of-the-art factory in Suzhou, China, covers an area of 35,000 square meters and employs nearly 100 professional technicians, further ensuring that each piece of equipment is manufactured to the highest standards.
The Chocolate Chips Rotary Depositor from Gusu Food Processing Machinery Suzhou Co., Ltd. offers an ideal solution for chocolate manufacturers seeking precision and stability in their production processes. With features like accurate feeding, continuous operation, and versatility, this equipment is a game-changer for producing uniform and high-quality chocolate chips.
